The core function of AAC Tilting Table plays an important auxiliary role in the whole process of aerated concrete production. It can mechanically flip the mold 90 degrees in the air, so that the mold side plate becomes the support base of the green body, which is convenient for subsequent cutting operations. Therefore, when we set up this part, we will connect it with cutting machines and maintenance trolleys, improve the automation of the production process, improve production efficiency and reduce manual intervention, and support large-scale continuous production.
1. Demolding Assistance: After flipping, the mold separates from the green block, preventing adhesion and damage to the green block structure.
2. Process Integration: Provides stable green block positioning for the cutting process, ensuring six-sided cutting accuracy (error < 2mm).
3. Capacity Increase: Shortens process intervals through mechanized operation; small production lines can achieve a capacity of up to 15 cubic meters per hour.
1. Pre-operation Check: Check that the hydraulic system pressure is stable (recommended working pressure 10-12MPa).
2. Regular Maintenance: Replace the sealing rings every 200 batches to prevent steam leakage from affecting equipment lifespan.
3. Environmental Adaptability: In Northeast China during winter, hydraulic oil preheating should be strengthened; in high-temperature areas in the South, pay attention to the maintenance of the cooling system.
4. Safety Protection: Operators must wear dust masks, and dust collection devices must be installed in the mixing area.
